MCCB molded case metering reclosing circuit breaker automatic two-dimensional code laser marking equipment

Short Description:

QR Code Printing: The device can automatically print QR code logo on the MCCB circuit breaker according to the preset logo rules. QR code is a kind of graphic code that can store a large amount of information, which is very convenient and practical in product management and tracking.

Marking rules configuration: The device can configure the marking rules of the QR code, such as code format, marking content, position, etc.. This allows you to set up the appropriate 2D code marking method according to the actual needs.

Laser printing technology: The device uses laser printing technology for 2D code marking. Laser printing has the advantages of high precision, high clarity and long-term stability, which can ensure the clarity and durability of the marking.

Data management: The equipment can correlate and manage the printed QR code marking with product information. The QR code can be scanned to quickly obtain relevant information about the product, such as production date, batch, specifications, etc.

Automated operation: The equipment can realize automated operation process, including automatic identification of products, automatic printing of logos, automatic recording of information and so on. It can improve working efficiency and accuracy.

Send email to us

Photograph

Parameters

Video

Previous: MCCB molded case metering reclosing circuit breaker automatic opening distance, overtravel detection equipment

Next: MCCB molded case metering reclosing circuit breaker automatic assembly equipment

1. Equipment input voltage: 380V ± 10%, 50Hz; ± 1Hz;
2. Device compatibility specifications: 2P, 3P, 4P, 63 series, 125 series, 250 series, 400 series, 630 series, 800 series.
3. Equipment production rhythm: 28 seconds per unit and 40 seconds per unit can be optionally matched.
4. The same shelf product can be switched between different poles with one click or scan code switching; Switching between different shell shelf products requires manual replacement of molds or fixtures.
5. Equipment fixtures can be customized according to the product model; The QR code definition range is 24 digits.
6. The equipment has alarm display functions such as fault alarm and pressure monitoring.
7. There are two operating systems available: Chinese and English.
8. All core accessories are imported from different countries and regions such as Italy, Sweden, Germany, Japan, the United States, Taiwan, etc.
9. The device can be equipped with functions such as the “Smart Energy Analysis and Energy Conservation Management System” and the “Smart Equipment Service Big Data Cloud Platform”.
10. Having independent and independent intellectual property rights.
