MCCB automatic high voltage testing equipment

Short Description:

High Voltage Withstand Test: This equipment is capable of performing high voltage withstand tests on MCCBs to verify their insulation and voltage withstand capabilities. By applying a high voltage current, it can test whether the MCCB can safely withstand the rated voltage and current.

Automated testing: This equipment can automate the test by automatically applying high voltage current through a preset program, recording the test results and generating a test report. This greatly improves testing efficiency and accuracy.

Protection: High-voltage test equipment is usually equipped with current overload, short-circuit and over-temperature protection to ensure the safe operation of the equipment and the safety of the operator.

Data Recording and Analysis: This equipment is capable of recording data from the testing process, including test time, current and voltage values, etc., for subsequent analysis and evaluation.

Send email to us

Photograph

Parameters

Video

Previous: MCCB automatic pad printing, laser marking and inspection equipment

Next: MCCB Automatic Mechanical Characterization Testing Equipment

1. Equipment input voltage 380V ± 10%, 50Hz; ± 1Hz;
2. Device compatibility specifications: 2P, 3P, 4P, 63 series, 125 series, 250 series, 400 series, 630 series, 800 series.
3. Equipment production rhythm: 28 seconds per unit and 40 seconds per unit can be optionally matched.
4. The same shelf product can be switched between different poles with one click or scan code switching; Switching between different shell shelf products requires manual replacement of molds or fixtures.
5. The equipment fixtures can be customized according to the product model.
6. The high voltage withstand time of 1-99 seconds can be arbitrarily set as the judgment value; The output voltage of 0-5000V can be set arbitrarily.
7. High voltage resistance detection position: When the product is in the open state, it detects the high voltage resistance between the incoming and outgoing lines; Detect the high voltage resistance between phases when the product is in a closed state; Detect the high voltage resistance between the phase and the bottom plate when the product is in a closed state; When the product is in a closed state, it detects the high voltage resistance between the phase and the handle.
8. The equipment has alarm display functions such as fault alarm and pressure monitoring.
9. There are two operating systems available: Chinese and English.
10. All core accessories are imported from different countries and regions such as Italy, Sweden, Germany, Japan, the United States, Taiwan, etc.
11. The device can be equipped with functions such as the “Smart Energy Analysis and Energy Conservation Management System” and the “Smart Equipment Service Big Data Cloud Platform”.
12. Having independent and independent intellectual property rights
