RCBO Leakage circuit breaker automatic assembly equipment

Short Description:

Automatic assembly: The equipment can automatically complete the assembly of earth leakage circuit breakers, including assembling different parts together, connecting wires and cables, and installing trigger devices. Through automated assembly, it improves assembly efficiency and consistency, and reduces labor costs and human errors.

Detection and judgment: The equipment has the function of detection and judgment, which can detect the assembly quality of the earth leakage circuit breaker, check whether the connection points are fixed and reliable, and whether the wires are in good contact. At the same time, the equipment can judge whether the assembly meets the requirements according to the set standards or parameters, and give the qualified or unqualified results.

Troubleshooting: The equipment can automatically carry out troubleshooting and repair. Once the problems or faults in the assembly are found, the equipment can ensure the assembly quality and performance by automatically adjusting or instructing the operator to repair.

Data Recording and Management: The equipment can automatically record and manage data during the assembly process. This includes the recording and storage of assembly parameters, assembly time, assembly quantity and other information. These data can be used for quality tracing, statistical analysis and other purposes.

Automation control: the equipment can realize automatic operation through the control system. Including automatic switching of power supply, automatic control of the assembly process, automatic adjustment of assembly parameters and so on. Through automation control, assembly efficiency is improved and human errors in the process are reduced.

Send email to us

Photograph

Parameters

Video

Previous: RCBO Leakage circuit breaker automatic leakage detection equipment

Next: RCBO Leakage circuit breaker automated production line

1. Equipment input voltage: 220V ± 10%, 50Hz; ± 1Hz;
2. Device compatible poles: 1P, 2P, 3P, 4P, 1P+module, 2P+module, 3P+module, 4P+module.
3. Equipment production rhythm: ≤ 10 seconds per pole.
4. The same shelf product can be switched between different poles with one click or scan code switching; Switching products requires manual replacement of molds or fixtures.
5. Assembly method: manual assembly and automatic assembly can be selected at will.
6. The equipment fixtures can be customized according to the product model.
7. The equipment has alarm display functions such as fault alarm and pressure monitoring.
8. There are two operating systems available: Chinese and English.
9. All core accessories are imported from different countries and regions such as Italy, Sweden, Germany, Japan, the United States, Taiwan, etc.
10. The device can be equipped with functions such as the “Smart Energy Analysis and Energy Conservation Management System” and the “Smart Equipment Service Big Data Cloud Platform”.
11. Having independent and independent intellectual property rights.
