IoT Intelligent Miniature Circuit Breaker Automatic Rollover Equipment

Short Description:

Remote monitoring and control: through IoT technology, the status and operation of the miniature circuit breaker can be remotely monitored to achieve remote control of the circuit breaker, which is convenient for users to carry out remote equipment management.

Automatic flip-flop: the equipment can automatically control the switching state of miniature circuit breakers to flip-flop according to the schedule set by the user or automatically identify the load condition, in order to avoid overload or fault conditions.

Fault Detection and Alarm: Equipped with fault detection function, the device can monitor the rated current, temperature and voltage of the miniature circuit breaker in real time, and will send an alarm to notify the user in time once an abnormal situation is found.

Historical data recording and analysis: the device will record the operation records, load conditions and other data of the miniature circuit breaker, and users can view the historical data through mobile app or cloud platform for data analysis and fault diagnosis.

Safety Protection: The device will monitor the environmental parameters around the miniature circuit breaker, such as temperature and humidity, to prevent overheating or other safety hazards, and send timely alarm messages to the user.

Energy-saving management: The device can carry out energy management through intelligent algorithms according to the user’s demand and power consumption planning, so as to achieve the goal of energy saving and emission reduction.

Interface and interconnectivity: the device will provide various interfaces and communication protocols to interconnect with other IoT devices or smart home systems to achieve smart home integration and linkage.

Send email to us

Photograph

Parameters

Video

Previous: Internet of Things intelligent miniature circuit breaker automatic instantaneous detection equipment

Next: IoT Intelligent Miniature Circuit Breaker Automatic Side Pad Printing Equipment

1. Equipment input voltage; 380V ± 10%, 50Hz; ± 1Hz;
2. Device compatibility poles: 1P, 2P, 3P, 4P, 1P+module, 2P+module, 3P+module, 4P+module.
3. Equipment production rhythm: ≤ 10 seconds per pole.
4. The same shelf product can be switched between different poles with just one click or by scanning the code.
5. The equipment fixtures can be customized according to the product model.
6. The equipment has alarm display functions such as fault alarm and pressure monitoring.
7. There are two operating systems available: Chinese and English.
8. All core accessories are imported from different countries and regions such as Italy, Sweden, Germany, Japan, the United States, and Taiwan.
9. The equipment can be optionally equipped with functions such as the Smart Energy Analysis and Energy Conservation Management System and the Smart Equipment Service Big Data Cloud Platform.
10. Having independent independent intellectual property rights.
