IOT intelligent miniature circuit breaker automatic coding equipment

Short Description:

Automatic identification and positioning: the equipment can automatically identify the type and position of miniature circuit breakers through image recognition technology, and carry out positioning to ensure the accuracy of spray coding.

Automatic coding: the equipment can automatically complete the coding operation of miniature circuit breaker, including selecting the coding content, setting the coding position and direction, etc., no need for manual intervention, improve production efficiency.

Parameter Setting and Adjustment: The equipment can set and adjust the parameters of coding according to different specifications and requirements of circuit breakers, such as coding speed, height and angle of the coding head.

Coding Quality Inspection: The equipment can inspect the quality after coding, such as the clarity and contrast of the coded content, to ensure that the coding meets the standards.

Data collection and analysis: the equipment can collect and analyse data on the coding process, and collect data on the quality of coding and the operating condition of the equipment, which is convenient for production management and quality control.

Remote monitoring and control: the equipment can be connected through the Internet of Things to realise remote monitoring and control functions, which is convenient for operators to understand the running status of the equipment at any time and carry out remote operation and adjustment.

Troubleshooting and Alarm: The equipment is equipped with troubleshooting function, once equipment failure or abnormality is found, it will alarm and provide corresponding troubleshooting information in time, which is convenient for timely repair and maintenance.

Send email to us

Photograph

Parameters

Video

Previous: IOT intelligent miniature circuit breaker automatic coding equipment

Next: Internet of Things intelligent miniature circuit breaker automatic laser, coding equipment

1. Equipment input voltage; 220V/380V ± 10%, 50Hz; ± 1Hz;
2. Device compatibility poles: 1P, 2P, 3P, 4P, 1P+module, 2P+module, 3P+module, 4P+module.
3. Equipment production rhythm: ≤ 10 seconds per pole.
4. The same shell frame product can be switched with one click for different pole numbers; Different shell products require manual replacement of molds or fixtures.
5. The equipment fixtures can be customized according to the product model.
6. The spray code parameters can be pre stored in the control system and automatically retrieved; The spray code parameters can be set arbitrarily, generally ≤ 24 bits.
7. The equipment has alarm display functions such as fault alarm and pressure monitoring.
8. There are two operating systems available: Chinese and English.
9. All core accessories are imported from different countries and regions such as Italy, Sweden, Germany, Japan, the United States, and Taiwan.
10. The equipment can be optionally equipped with functions such as the Smart Energy Analysis and Energy Conservation Management System and the Smart Equipment Service Big Data Cloud Platform.
11. Having independent independent intellectual property rights.
