Energy Meter Production Line

Short Description:

System Features:
Adopting multi-specification mixed production, automation, informatization, modularization, flexibilization, customization, visualization, cloud computing, one-key switching, early warning notification, evaluation report, data collection and processing, global inspection management, full life cycle management of the equipment, more advanced, smarter, more reliable, highly integrated, intelligent scheduling, remote maintenance design concepts.

Equipment Function:
With automatic product loading base, assembly of conductive columns, assembly of circuit boards, soldering, locking screws, assembly of seals, assembly of glass cover, assembly of the outer ring, locking screws, characteristics testing, day-timing test, error calibration, voltage testing, full-screen testing, characteristics of the comprehensive testing, laser marking, automatic labeling, carrier detection, infrared function detection, Bluetooth communication detection, recalibration testing, assembly of nameplates, scanning the code of the asset information Data comparison, qualified and unqualified distinction, packaging, palletizing, AGV logistics, lack of material alarms and other processes of assembly, online testing, real-time monitoring, quality traceability, barcode identification, component life monitoring, data storage, MES system and ERP system networking, parameters of any recipe, intelligent energy analysis and energy-saving management system, intelligent equipment services, big data cloud platform and other functions.


See More>>

Photograph

Parameters

Video

1

2

3

4


  • Previous:
  • Next:

  • 1. Equipment input voltage 380V ± 10%, 50Hz; ± 1Hz;
    2. Equipment compatibility: State Grid/South Grid, single-phase energy meter series, three-phase energy meter series.
    3. Equipment production rhythm: 30 seconds per unit, and can be customized according to customer requirements.
    4. The same shelf product can be switched between different poles with just one click or by scanning the code; Switching between different shell products requires manual replacement of molds or fixtures.
    5. Assembly methods: manual assembly and automatic assembly can be freely selected.
    6. The equipment fixtures can be customized according to the product model.
    7. The equipment has alarm display functions such as fault alarm and pressure monitoring.
    8. There are two operating systems available: Chinese and English.
    9. All core accessories are imported from different countries and regions such as Italy, Sweden, Germany, Japan, the United States, and Taiwan.
    10. The equipment can be optionally equipped with functions such as the Smart Energy Analysis and Energy Conservation Management System and the Smart Equipment Service Big Data Cloud Platform.
    11. Having independent independent intellectual property rights.
