Energy meter external low voltage circuit breaker manual module assembly assembly equipment

Short Description:

Component assembly: the equipment is capable of automatically completing the assembly of manual modules for power meters and low-voltage circuit breakers, including the work of connecting wires, fixing screws, and installing fittings, etc., so as to improve the production efficiency and assembly quality.

Condition checking: the equipment has the ability to check the conditions of the assembled modules, such as checking whether the length of the connecting wires meets the requirements, whether the screws are loose, etc., to ensure the accuracy and reliability of the assembly.

Quality inspection: the equipment is capable of carrying out quality inspection on the assembled external low-voltage circuit breaker of the power meter, such as inspecting the accuracy of the reading of the power meter and the on-state of the circuit breaker, etc., to ensure that the quality of the product meets the standard requirements.

Troubleshooting: the equipment is equipped with troubleshooting function, which can detect and identify possible problems in the assembly process of components, such as loose connecting wires, missing screws, etc., and carry out timely alarm and treatment.

Data Recording and Management: The equipment can record the data of each assembly, including time, assembly parameters, quality inspection results, etc., which is convenient for subsequent quality tracking and management.

Convenient operation: the equipment is equipped with user-friendly operation interface and control system, which can set the assembly parameters, adjust the assembly speed and pressure to adapt to different assembly requirements.

Automatic control: the equipment is equipped with automatic control capability, which can automatically complete the assembly work according to the preset procedures, reducing manual intervention and operational errors.

Send email to us

Photograph

Parameters

Video

Previous: Energy meter external low voltage circuit breaker automatic piercing and riveting equipment

Next: Energy meter external low-voltage circuit breaker automatic time-delay recalibration testing equipment

1. Equipment input voltage; 220V ± 10%, 50Hz; ± 1Hz;
2. Device compatibility poles: 1P, 2P, 3P, 4P, 1P+module, 2P+module, 3P+module, 4P+module.
3. Equipment production rhythm: ≤ 10 seconds per pole.
4. The same shelf product can be switched between different poles with just one click or by scanning the code; Switching products requires manual replacement of molds or fixtures.
5. Assembly methods: manual assembly and automatic assembly can be freely selected.
6. The equipment fixtures can be customized according to the product model.
7. The equipment has alarm display functions such as fault alarm and pressure monitoring.
8. There are two operating systems available: Chinese and English.
9. All core accessories are imported from different countries and regions such as Italy, Sweden, Germany, Japan, the United States, and Taiwan.
10. The equipment can be optionally equipped with functions such as the Smart Energy Analysis and Energy Conservation Management System and the Smart Equipment Service Big Data Cloud Platform.
11. Having independent independent independent intellectual property.
