Energy meter external low-voltage circuit breaker automatic coding equipment

Short Description:

Automatic coding: the equipment can automatically spray code information such as identification codes and serial numbers onto energy meters and low-voltage circuit breakers without manual intervention. Through the use of inkjet or laser technology, high-speed and accurate coding operation can be achieved.

Positioning of coding position: the equipment can precisely locate the coding position on energy meters and low-voltage circuit breakers to ensure the accuracy of coding. The use of photoelectric sensors, cameras and other technologies can be reliably positioned on products of different sizes and shapes.

Flexible and Variable Printing Contents: The equipment can flexibly set and change the printing contents on energy meters and low-voltage circuit breakers according to the needs. It can include product model, production date, batch number, enterprise logo and other information to meet the needs of different industries and customers.

Coding speed adjustment: the equipment has the function of adjusting the coding speed, which can be set according to the actual situation of the production line. It can achieve high-speed and stable coding, improve production efficiency and ensure coding quality.

Colour and font selection: The equipment supports a variety of coding colour and font selection, which makes the coding result more rich and clear. Monochrome, multi-colour and multiple font styles can be achieved to meet the needs of different products and customers.

Detection and Error Correction Mechanism: The device has built-in coding detection and error correction mechanism, which can automatically detect the quality and accuracy of coding. If problems such as skewed, blurred or missing codes are found, the equipment will automatically correct or alarm to ensure the reliability of the codes.

Data Record and Traceability: The equipment can record the relevant data of each coding, such as time, content, location, etc., so as to facilitate the subsequent data analysis and product traceability. At the same time, relevant reports can be generated for quality control and management.

Send email to us

Photograph

Parameters

Video

Previous: Energy meter external low voltage circuit breaker automatic piercing equipment

Next: Energy meter external low-voltage circuit breaker automatic laser, printing code equipment

1. Equipment input voltage: 220V/380V ± 10%, 50Hz; ± 1Hz;
2. Device compatibility poles: 1P, 2P, 3P, 4P, 1P+module, 2P+module, 3P+module, 4P+module.
3. Equipment production rhythm: ≤ 10 seconds per pole.
4. The same shell frame product can be switched with one click for different pole numbers; Different shell products require manual replacement of molds or fixtures.
5. The equipment fixtures can be customized according to the product model.
6. The spray code parameters can be pre stored in the control system and automatically retrieved; The spray code parameters can be set arbitrarily, generally ≤ 24 bits.
7. The equipment has alarm display functions such as fault alarm and pressure monitoring.
8. There are two operating systems available: Chinese and English.
9. All core accessories are imported from different countries and regions such as Italy, Sweden, Germany, Japan, the United States, and Taiwan.
10. The equipment can be optionally equipped with functions such as the Smart Energy Analysis and Energy Conservation Management System and the Smart Equipment Service Big Data Cloud Platform.
11. Having independent independent intellectual property rights.
