Double-breakpoint moulded case circuit breaker automated production line

Short Description:

Automated production: the production line adopts automated equipment and robot technology, which can realise automatic assembly, testing and packaging of circuit breakers and improve production efficiency and quality stability.

Efficient production capacity: the automated production line can realise high-speed production, which greatly improves the production efficiency, shortens the production cycle and meets the market demand.

Precise production: the production line is equipped with advanced sensors and control systems, which can achieve precise assembly and testing of circuit breakers and ensure product quality.

Flexible production: the production line has a certain degree of flexibility, can adapt to the production of different specifications and models of circuit breakers, to meet the individual needs of customers.

Energy-saving and environmental protection: the automated production line adopts energy-saving equipments and processes, which reduces energy consumption and waste generation and meets the requirements of environmental protection.

Send email to us

Photograph

Parameters

Video

Previous: Aluminium profile anti-static workbench Flow line workbench Workshop assembly table Electronic factory operating table Manual table operation double layer with light assembly workshop Profile customised non-standard Production line table Factory assembly maintenance packing table

Next: MCB DC Miniature Circuit Breaker Automatic Production Line

1. Equipment input voltage 380V ± 10%, 50Hz; ± 1Hz;
2. Device compatibility: 2P, 3P, 4P, 63 series, 125 series, 250 series, 400 series, 630 series, 800 series.
3. Equipment production rhythm: 28 seconds per unit and 40 seconds per unit can be optionally matched.
4. The same shelf product can be switched between different poles with just one click or by scanning the code; Switching between different shell products requires manual replacement of molds or fixtures.
5. Assembly methods: manual assembly and automatic assembly can be freely selected.
6. The equipment fixtures can be customized according to the product model.
7. The equipment has alarm display functions such as fault alarm and pressure monitoring.
8. There are two operating systems available: Chinese and English.
9. All core accessories are imported from different countries and regions such as Italy, Sweden, Germany, Japan, the United States, and Taiwan.
10. The equipment can be optionally equipped with functions such as the Smart Energy Analysis and Energy Conservation Management System and the Smart Equipment Service Big Data Cloud Platform.
11. Having independent independent intellectual property rights.
