AC Contactor AutomaticProduction Line

Short Description:

Automated Assembly: Flexible production lines are capable of automating the contactor assembly process, including automatic feeding, transfer, and assembly. Through the use of robots and automated equipment, production efficiency and consistency can be increased and manual labor can be reduced.

Flexible Production: Flexible production lines have the ability to adapt to various specifications and models of contactor assembly. Processes and equipment can be quickly adjusted to fit different specifications and models of contactors according to product demand.

Inspection and quality control: The flexible production line is equipped with inspection equipment and systems that can automate the inspection and control of contactors. For example, the appearance, size, and electrical properties of the contactors are detected and automatically categorized, screened, and marked.

Data management and traceability: The flexible production line is able to record and manage a variety of data during the contactor production process, including production parameters, quality data, equipment status, and so on. These data can be used for production process optimization, quality analysis and traceability.

Flexible Adaptation to Changes: The flexible production line can quickly adapt to market demand and product changes, and realize fast delivery and flexible production by quickly adjusting and switching equipment.

Fault diagnosis and maintenance: Flexible production lines are equipped with fault diagnosis and prediction systems that can monitor the status and performance of equipment in real time. When faults or abnormalities occur, it can issue timely alarms or automatic shutdowns and provide maintenance guidance.

Send email to us

Photograph

Parameters

Video

Previous: CJX2S automatic coring equipment with equipment

Next: Magnetic switch automated production line

1, equipment input voltage: 380V ± 10%, 50Hz; ± 1Hz
2, equipment compatible specifications: CJX2-0901, 0910, 1201, 1210, 1801, 1810.
3, equipment production beat: 5 seconds / unit, 12 seconds / unit two optional.
4, different specifications of the product can be a key to switch or sweep code switch can be; switching between different shell frame products need to manually replace or adjust the mold / fixture, manual replacement / adjustment of different products accessories.
5、Assembly mode: manual assembly, automatic assembly can be optional.
6、Equipment fixture can be customized according to the product model.
7、Equipment with fault alarm, pressure monitoring and other alarm display function.
8, Chinese and English version of the two operating systems.
All core parts are imported from Italy, Sweden, Germany, Japan, the United States, Taiwan and other countries and regions.
10、Equipment can be equipped with optional functions such as “Intelligent Energy Analysis and Energy Saving Management System” and “Intelligent Equipment Service Big Data Cloud Platform”.
11、It has independent independent intellectual property rights.
